We are proud to offer this particular V6 hotend. We have sifted through many sources, to find a offer a high quality V6 clone to you. Since, we service many large printer customers, we have found this particular bundle to be of great value to CR-10, S4, and S5 owners. It comes bundled with a Volcano clone heat block, Volcano style nozzles, and a passthrough thermal tube. This passthrough tube, allows the bowden to travel through, the thermal tube (heat break), and stop at the the nozzle.
You will need to print a mount (see this link) to bolt this hotend to your CR-10, S4, or S5 carriage. I nice part cooler for 40mm fan is (see this link). If you are careful, you can reuse your existing heater cartridge, and thermistor, to save having to join wires. You will also need to print, (or slot exisitng mounting holes) in your Z-axis endstop switch mount (see link for Z switch mount). This is because the hot end will hang lower than your stock hotend. Making the adjustment of the endstop switch is quite simple, once you have the adjustable endstop mount.
An All metal tube for this V6 clone is also available from MacEwen 3D. We do the vetting for you. If it's not great, you will not find it here.
This package includes:
- V6 hot end (assembled with standard heater block)
- 100 K Thermistor (39.5 inch leads) Same type as stock.
- No firmware changes are required or recommended.
- 30W Heater cartridge (39.5 inch leads) 12V
- V6 Fan Mount, for 30 mm Fan
- 12V 30 mm Fan
- Volcano Style Heater Block
- Volcano 4-piece Brass Nozzle Set (0.6, 0.8, 1.0, and 1.2 mm bores)
- Standard V6 nozzle (0.4 mm bore)
- 39.5 inch Long Bowden Tube (1 meter)
- We include an upgraded Bowden tube fitting (the white brass ones out there aren't so great)
-
Click for Simple PDF.
-
Click for Long form PDF, check list to ensure your wiring is correct before powering up.
We will be happy to address any questions, you may have during your installation.
We definitely recommend wrapping wires with Kapton / Polyamid tape anywhere it may be pinched. If installing the included Volcano option, small pieces can be applied to the bottom of heatsink, and heater block itself, where wires can be pinched. A little extra protection goes a long way.
We also carry replacement stainless nozzles, fans, and Bowden tube fittings, and all metal thermal tube for this V6. What ever your are looking to do, we are happy to help.
Here are a few links to printable files, which will help with this modification:
CR-10 V6 Mounts to Thingiverse
UPDATE: Recently added and recommended solution (below):
This is a great design to mount the V6 to your CR-10, S4, or S5 printer. It mounts the V6, and includes optional mount to use the volcano heater block (which sits lower). There is also a part to allow mounting your stock 40mm hotend fan.
CR-10 Heavy Duty customizable modular e3D V6 mount Volcano 5015 ABL (Link to Thingiverse)
CR-10 Adjustable Z Endstop Mount
